Arjo KMCEXN-D Maxi Move Floor Lifter without Scale, Extra-Low-Height Castors and Medium Powered DPS

Details

Maxi move is designed to enable a single caregiver to manage demanding everyday patient or resident transfer and repositioning tasks. It is a versatile solution that can be adapted using a variety of spreader bars to accommodate patient transfer needs.

Stable vertical lifting action keeps the patient at a constant distance from the mast and in a stable position during lifting and transferring.

Integrated with the spreader bar is a powered dynamic positioning system (PDPS) that enables the patient to be repositioned in the sling, minimizing the need for manual handling.

Optional interchangeable spreader bars give caregivers a flexible system that also enables them to select from a comprehensive range of slings.

Dual action telescopic mast, which can be combined with an extended jib, offers a wide lifting range for lifting onto beds and from the floor.

Optional scale available, as well as three sizes of castors including extra-low to facilitate access under low couches and trolleys.

Features:

  • Powered dynamic positioning system (PDPS) minimizes manual handling and improves precision when positioning the patient.
  • The Combi attachment makes it smooth and easy to change between different spreader bars and stretcher frames.
  • Dual controls on the mast and the hand control. Using the hand control gives the caregiver the opportunity to move and stay close to the patient and maintain good eye contact throughout the lift and transfer process.
  • Vertical mast provides stability while the patient is lifted.
  • Three castor sizes available: standard, low and extra-low to facilitate access under low beds and trolleys.
  • Optional integrated scale supports an efficient weighing routine.
Write a review
In stock
SKU
CESS-861200-00001
MPN
KMCEXN-D
Features include: Low-height castors and medium powered DPS, dual controls on the mast and the hand control, vertical mast provides stability while the patient is lifted, dual action telescopic mast.
$13,006.66
Specifications
DiscontinuedNo
Additional Specifications:
  • Product Type: Move Floor Lifter
  • Max Safe Working Load: 500 lbs
  • Max Safe Working Load if Equipped with Extended Jib: 287 lbs
  • Lifter Weight (with Spreader bar and battery): 154 lbs
  • Includes: Without Scale, Extra-Low-Height Castors and Medium Powered DPS
  • Max Lifting Height: 62"
  • Min Lifting Height: 8.75"
  • Lifting Stroke: 53.12"
  • Min Total Storage Height: 55.25"
  • External Width Legs Closed: 28.25"
  • External Width Legs Open: 47.12"
  • Internal Width Leg Closed: 22.75"
  • Internal Width Leg Open: 42.25"
  • Leg Clearance (Floor to Top Of Legs) - Standard Castors: 4.5"
  • Leg Clearance (Floor to Top Of Legs) - Low Castors: 4"
  • Leg Clearance (Floor to Top Of Legs) - Extra Low Castors: 2.25"
  • Chassis Clearance (Floor to Bottom of Chassis) - Standard & Low Castors: 1"
  • Chassis Clearance (Floor to Bottom of Chassis) - Extra Low Castors: 0.75"
  • Lifter Length: 44"
  • Turning Diameter: 48"
  • Lifter Protection Class: IPX4
  • Hand Control Protection Class: IPX7
  • Battery: 24V 4Ah
Unit of Measure (UOM)Each
