Details

Featuring Masimo SET Measure-through Motion and Low Perfusion pulse oximetry with upgradeable rainbow SET technology.

In a study comparing three pulse oximetry technologies, Masimo SET demonstrated the highest sensitivity and specificity in identifying desaturation events during conditions of motion and low perfusion.

Features:

• Optional two-way camera supports video conferencing
• Bright high-resolution, LCD color display
• Ambient light sensor automatically adjusts screen brightness, optimizing visibility
• Redesigned connector with a slim profile design provides tactile feedback upon proper connection
• Profile icon changes and home button illuminates in corresponding colors to provide visual indications of the current Profile setting
• System status light provides visual indications of alarms and system messages
• Rechargeable Li-ion battery, with approximately four hours of power
• AC power connector (110V/220V, 47-63 Hz) provides a more secure hold between power cable and device
• Swivel foot provides additional support when in vertical orientation

• Oxygen Saturation
• Pulse Rate
• Perfusion Index
• Pleth Variability Index

• Total Hemoglobin
• Carboxyhemoglobin
• Methemoglobin
• Oxygen Content
• Acoustic Respiration Rate

• Customizable display allows for quick assessment of patient status and provides pertinent data at a glance
• Configurable patient profile settings for a variety of patient populations
• Connectivity solutions for electronic charting of patient data in the EMR, automated by Patient SafetyNet* or Iris Gateway
• Upgradeable rainbow SET technology allows for continuous monitoring of multiple additional parameters

• WiFi (802.11abg)
• Bluetooth LE
• Nurse Call Interface
• Ethernet
• USB Port

Adjust the range of trend time displayed and quickly navigate the user interface with intuitive finger gestures.

Trend 96 hours of parametric data to analyze patient status over time.

Optional Integrated Camera Observe and communicate with patients remotely from Patient SafetyNet view stations.

Audible and visual alarms for quick identification of alarming parameter.

• Safety Standard(s): ANSI/AAMI ES 60601-1, CAN/CSA C22.2 No. 60601-1, IEC/EN 60601-1, 3rd Ed
• Pulse Oximeter Standard(s): ISO 80601-2-61
• Alarm Standard(s):IEC 60601-1-8
• EMC Standard(s): EN 60601-1-2, Class B
• Type of Protection: Class I (AC power) / Class II (Internally Powered)
• Degree of Protection: Type BF, Defib Proof-Applied Part
• Mode of Operation (per IEC 60601-1): Continuous Operation
• Enclosure Degree of Protection: IP22
