The GE B125 V3 patient monitor includes NIBP, IBP, temperature, printer, 3 and 5 lead ECG, extension rack, and battery.
The GE B125 V3 patient monitor is a portable multi-parameter unit designed to be used for monitoring, recording, and to generate alarms for multiple physiological parameters of adult, pediatric, and neonatal patients in a hospital environment and during intra-hospital transport.
The B125 patient monitor is able to detect and generate alarms for the following ECG arrhythmias: Asystole, Ventricular tachycardia, VT>2, Ventricular Bradycardia, Accelerated Ventricular Rhythm, Ventricular Couplet, Bigeminy, Trigeminy, "R on T", Tachycardia, Bradycardia, Pause, Atrial Fibrillation, Multifocal PVCs, Missing Beat, Premature Ventricular Contraction (PVC) and Ventricular fibrillation.
Features:
Seven pre-configured workflow settings for simple set-up
Auto-snapshot of most critical alarms
Alarm reporting options for better alarm management and instant care in cases of arrhythmia, high/low blood pressure, and ECG-lead detachment
Convenient screen lock button for easy cleaning, maintenance, and intra-hospital transport
Capacitive touchscreen for fast response and enhanced user experience
Uninterrupted display of primary ECG-lead waveform and other vital signs across settings
Choice of numerical or continuous waveform monitoring
Large numeric mode that enables critical parameter visibility even up to four meters
Controls: Capacitive Touch Screen and Trim Knob Control and Hard Keys (Standard)
ECG:
Leads Available:
3-Lead Configuration: I, II, III
5-Lead Configuration: I, II, III, aVR, aVL, aVF, and V
Sweep Speed: 12.5, 25, or 50 mm/s
Gain Range: 0.5 x , 1 x, 2 x, and 4 x
Heart Rate Accuracy: 30 to 300 bpm, +/- 5% or +/-5 bpm, whichever is greater
50/60 Hz Power Supply:
Monitor: 0.5 to 40 Hz
ST: 0.05 to 40 Hz
Diagnostic: 0.05 to 145 Hz
Pacemaker Detection:
Range: 2 to 700 mV.
Pulse Width: 0.5 to 2 ms
Arrhythmia Analysis: Asystole, V Fib / V Tach, V Tach, VT>2 R on T, V Brady, Couplet, Bigeminy, Accelerated Ventricular arrhythmia, Multifocal PVCs, A Fib, Missing beat, Pause, Tachy, Brady, Trigeminy
ST Segment Analysis:
Numeric Range: -9 to +9 mm (-0.9 to +0.9 mV)
Accuracy: +/- 0.2 mm or +/- 10%, whichever is greater, within the measurement range of -8 to 8 mm
Numeric Resolution: 0.1 mm (0.01 mV)
ST Trends: Up to 168h
Range:
Adult/Pediatric: 4 to 120 resp/min
Neonate: 4 to 180 resp/min
Accuracy: +/- 5% or +/- 5 resp/min, Whichever is Greater
Gain Range: 0.1 to 5 cm/Ohm
SpO2:
GE:
Pulse Oximetry Measurement Range: 1 to 100%
Pulse Rate: 30 to 250 bpm
Saturation Measurement Accuracy:
Without Motion-Adult/Pediatric Finger Sensor: 70 to 100% +/- 2%
Without Motion-Neonate: 70 to 100% +/- 3%
With Motion-Adult/Pediatric/Neonate: 70 to 100% +/- 3%
Low Perfusion-Adult/Pediatric: 70 to 100% +/-3% (1~69% Unspecified)
Pulse Rate: Without Motion: +/- 2 bpm (adult/pediatric/neonatal)
NIBP
Measurement Technique: Oscillometric with step deflation
Modes: Manual, Automatic, Stat
Systolic Measurement Range
Adult/Pediatric: 30 to 290 mmHg
Neonate: 30 to 260 mmHg
MAP Measurement Range:
Adult/Pediatric: 20 to 260 mmHg
Neonate: 20 to 125 mmHg
Diastolic Measurement Range:
Adult/Pediatric: 10 to 220 mmHg
Neonate: 10 to 110 mmHg
Accuracy: Meets AAMI ISO81060-2 and IEC 80601-2-30
Default Initial Inflation Pressure:
Adult/Pediatric: 135 +/- 15 mmHg
Neonate: 100 +/- 15 mmHg
Maximum Determination Time:
Adult/Pediatric: 2 min
Neonate: 100 +/- 15 mmHg
Over Pressure Monitor:
Adult/Pediatric: 294 +/-6 to 330 mmHg
Neonate: 147 +/- 3 to 165 mmHg
Invasive Blood Pressure:
Measurement Range: -40 to 320 mmHg (15.3 to 42.7 kPa)
Measurement Accuracy: +/- 5% or +/- 2 mmHg, Whichever is Greater
Frequency Response: 4 to 22 Hz
Transducer Sensitivity: 5 ?V/V/mmHg
Temperature:
Numerical Display: T1, T2, T2-T1
Measurement Range: 10 to 45 Degrees C (50 to 113 Degrees F)
Measurement Accuracy: +/- 0.1 Degrees C without Probe
