Details

GX Solutions and the i.C3 Information Center set i.Series models apart by providing a professional medical-grade refrigerator with advanced monitoring and control. The iBR226-GX is a two-door Pass-Thru Blood Bank Refrigerator (one door on each side) designed for use between two spaces. The iBR226-GX provides optimal conditions for storing blood products at 4?C. The advanced i.C3 touchscreen provides continuous temperature monitoring, event logs, and downloadable temperature graphs. Innovative OptiCool technology offers energy savings, quiet operation, and low heat output, in addition to the excellent temperature uniformity and recovery that are critical for blood storage. GX Solutions Pass-Thru refrigerators have undergone extensive use case testing to ensure they meet rigorous performance requirements, including multiple and extended door openings.

Features:

• Designed to safely store blood and blood components within an exceptional temperature-controlled environment
• OptiCool technology pairs a variable capacity compressor (VCC) and natural hydrocarbon refrigerants to ensure optimal temperature uniformity, recovery, and stability, efficiently manage energy consumption and meet evolving environmental regulations
• Optimized temperature uniformity, recovery and stability create best environment for blood storage
• U.S. Environmental Protection Agency SNAP (Significant New Alternatives Policy) compliant refrigerants
• Quiet operation creates fewer distractions and better working environment
• i.C3 touchscreen user interface is password protected and provides advanced monitoring and information to ensure protection of stored product
• Cabinet built with high-quality construction meets or exceeds performance standards required by the medical and scientific industries
• Adjustable, liquid-tight drawers for containment of spills
• Rear access port
• Insulation: Sustainable, US EPA, and SNAP approved foam
• Trim/Skirt Kit Details (sold separately ): Trim kit - side rails 3" x 81.8", top rail 3" x 35", 1 kit per side needed, Skirt kit - 2.7" x 29", Clean room side only, Bacteria-resistant powder-coating
• Access Port: Top Access Port- for external monitoring probe(s) (0.75" diameter)
• Casters: Yes, swivel-locking
• Clearance Requirements: Minimum of 8" above the ante-room (control) side of the refrigerator. Clearance above the solid cover on the clean room side may be 0".

Facility Supply Rating

Branch circuit with earth ground, meeting plug/cord ratings as well as local electrical safety codes and requirement

• 110-120V AC: 15 A (minimum)
• 220-240V AC: 10 A (minimum)

NEMA 5-15 hospital-grade | 115V 60Hz, 8 to 10 ft (2.4-3.0m) Inquire about additional plug/cord options

QPS (Certified to UL and CSA Standards), CE 2797, RoHS

• Refrigeration System: VCC compressor-based, forced-air hydrocarbon
• Compressor: Hermetic, variable speed (VCC). Rated speed range: 2000-3500 rpm
• Condenser Type: Air-cooled fin and tube, sealed
• Expansion Device: Cap tube
• Evaporator Type: Direct expansion with forced-air fin and tube
• Defrost Method: Automatic
• Refrigerant: R290, Propane, EU F-Gas and EPA SNAP compliant

• User Interface: i.C3 color touchscreen, door mounted, 7in | 177mm, ?C or ?F
• Power Switch: On/Off
• Controller Type: Microprocessor with touchscreen input & display
• Security: Lockable door, key lock
• Control Sensor: RTD, stainless steel
• Communication Ports: USB, Remote alarm contacts, RJ45 (Ethernet). API available for Ethernet connectivity development
• Power Failure Alarm: Yes
• High/Low Alarms - Tests: Yes, fully adjustable, automatic (Peltier) testing
• Door Ajar Alarm: Yes, fully adjustable
• Condenser Temperature Alarm: Yes, fully adjustable
• Min/Max Temperature: Yes, display and reset
• Download: Yes, via USB. CSV and PDF
• Event Log: Yes, all alarms, door openings, download via USB
• Temperature Log: Yes, download via USB
• Interactive Temperature Graph: Yes
• Chart Recorder: Yes, integrated, 4" diameter, inkless pressure-sensitive charts, backup battery
• Temperature Monitoring Ballast: Yes, two 4 oz bottles with screw caps, solid ballasts optional
• Battery Back-up: Yes, 20 hr display & alarm back up for i.C3 touchscreen | Rechargeable 12V, lead acid

Featured Options & Accessories

Solid Ballast Simulator Kit for GX Model Refrigerators

Solid Ballast Simulator is a maintenance-free thermal buffering solution designed to replace glycerin bottles. Uses existing wall or ceiling-mounted bracket.

Ventilated Shelf (Pass-Thru)

Full Shelf, Ventilated, White (with hardware). For field installation (for 26 and 58 cu ft Pass-Thru Refrigerators)

Drawer - i.Series w/Hardware, Pass-Thru

Drawer, 2-Way, Liquid-Tight, Stainless Steel (with slides), for Field Installation (for i.Series 26 and 58 cu ft Pass-Thru Refrigerators)
