Details

GX Solutions and the i.C3 Information Center set i.Series models apart by providing a professional medical-grade refrigerator with advanced monitoring and control. The iBR256-GX Blood Bank Refrigerator is a double door, upright model that provides optimal conditions for storing blood products at 4?C. The advanced i.C3 touchscreen provides continuous temperature monitoring, event logs, and downloadable temperature graphs. Tight temperature uniformity and reliable performance ensure that blood is safely stored. Innovative OptiCool technology offers energy savings, quiet operation, and low heat output, in addition to the excellent temperature uniformity and recovery that are critical for blood storage.

Features:

• OptiCool technology pairs a variable capacity compressor (VCC) and natural hydrocarbon refrigerants to ensure optimal temperature uniformity, recovery and stability, efficiently manage energy consumption and meet evolving environmental regulations
• Optimized temperature uniformity, recovery and stability create best environment for blood storage
• Reduced energy consumption (50-65% more efficient than traditional technology)
• U.S. Environmental Protection Agency SNAP (Significant New Alternatives Policy) compliant refrigerants
• Quiet operation (50 dB) creates fewer distractions and better working environment
• i.C3 touchscreen user interface is password protected and provides advanced monitoring and information to ensure protection of stored product
• Cabinet built with high-quality construction meets or exceeds performance standards required by the medical and scientific industries
• Adjustable, liquid-tight drawers for containment of spills
• Rear access port
• Energy Star certified
• Insulation: Sustainable, US EPA and SNAP approved foam
• Access Port: Top Access Port- for external monitoring probe(s) (0.75" | 19 mm diameter)
• Casters: Yes, swivel-locking
• Clearance Requirements: Minimum of 8" above and 3" behind unit for proper ventilation, clearance, and feature access

Facility Supply Rating

Branch circuit with earth ground, meeting plug/cord ratings as well as local electrical safety codes and requirements

• 110-120V AC: 15 A (minimum)
• 220-240V AC: 10 A (minimum)

NEMA 5-15 hospital-grade | 115V 60Hz, 8 to 10 ft (2.4-3.0m) Inquire about additional plug/cord options

QPS (Certified to UL and CSA Standards) IEC/UL61010-2-011 (Dec 2016), CE 2797, RoHS

Refrigeration

• Refrigeration System: VCC compressor-based, forced-air hydrocarbon
• Compressor: Hermetic, variable speed (VCC). Rated speed range: 1300-4000 rpm
• Condenser Type: Air-cooled fin and tube, sealed
• Expansion Device: Cap tube
• Evaporator Type: Direct expansion with forced-air fin and tube
• Defrost Method: Automatic
• Refrigerant: R600a, Isobutane, EPA SNAP compliant

• User Interface: i.C3 color touchscreen, door mounted, 7", ?C or ?F
• Power Switch: On/Off
• Controller Type: Microprocessor with touchscreen input & display
• Security: Lockable doors, password protected settings
• Control Sensor: RTD, stainless steel
• Communication Ports: USB, Remote alarm contacts, RJ45 (Ethernet). API available for Ethernet connectivity development
• Power Failure Alarm: Yes
• High/Low Alarms - Tests: Yes, fully adjustable, automatic (Peltier) testing
• Door Ajar Alarm: Yes, fully adjustable
• Condenser Temperature Alarm: Yes, fully adjustable
• Min/Max Temperature: Yes, display and reset
• Download: Yes, via USB. CSV and PDF
• Event Log: Yes, all alarms, door openings, download via USB
• Temperature Log: Yes, download via USB
• Interactive Temperature Graph: Yes
• Chart Recorder: Yes, integrated, 4" diameter, inkless pressure-sensitive charts, backup battery
• Temperature Monitoring Ballast: Yes, two 4 oz bottles with screw caps, solid ballasts optional
• Battery Back-up: Yes, 20 hr display & alarm back up for i.C3 touchscreen | Rechargeable 12V, lead acid

Featured Options & Accessories

Solid Ballast Simulator Kit for GX Model Refrigerators

Solid Ballast Simulator is a maintenance-free thermal buffering solution designed to replace glycerin bottles. Uses existing wall or ceiling-mounted bracket.

Solid Door

Ideal for storage of light-sensitive products or to reduce risk of diversion.

Top Panel Cover (56 Cu. Ft.)

Top cover for GX 56 cu ft upright refrigerator. Attachment materials provided.

Ventilated Shelf (25 & 56 Cu. Ft.)

Full Shelf, Ventilated, White (with hardware). For field installation (for 25 and 56 cu ft refrigerators and freezers, GX models)

Ventilated Drawer (25 & 56 Cu. Ft.)

Ventilated drawers are fully extendable and powder-coated (for 25 and 56 cu ft refrigerators, GX models). Hardware is included.

Solid Stainless Steel Drawers (25 & 56 Cu. Ft.)

Liquid-tight drawers contain spills and are fully extendable (for i.Series 25 and 56 cu ft Refrigerators).

Locking Drawers (25 & 56 Cu. Ft.)

Stainless-steel drawers with ventilated cover and key lock offer secure storage for medications, vaccines, blood products, samples, and more (for 25 and 56 cu ft Refrigerators).
