Details

The UltraCW II offers exceptional performance and consistent reproducible results with intuitive programming for high-performance automated cell washing. Tube testing is considered the gold standard for ABO and Rh grouping, antibody identification and cross-matching. The UltraCW II cell washer allows users to streamline workflows and complete wash cycles simply and efficiently.

Features:

• Intuitive programming allows user to create programs quickly with the easy-to-use touchscreen interface.
• Consistent, reproducible results; provides precise saline fills and digital calibration
• Ergonomic, compact footprint conveniently fits in your lab space
• High-capacity flexibility of 12 place rotors increases productivity and sample capacity
• Easy to use with saline directly connected to cell washer and convenient cleaning procedures
• Safe, quiet operation

• Exceptional performance and consistent, reproducible results with intuitive programming for high performance automated cell washing

• Create programs quickly with the easy-to-use touchscreen interface
• Achieve optimal results by customizing programs to your protocols
• Incorporate check and spin steps into programs making it easy to run wash cycles, add reagents, and perform a quick spin
• Use pre-set programs for convenience
• Create streamlined workflow with no need to transfer tubes to separate centrifuge for spin
• Track the progress of the process while the program is running

• Electronic flow meter provides precise saline fills
• Digital calibration offers easy and accurate control of saline volumes and eliminates time consuming, cumbersome manual calibration

• Low profile creates a comfortable and ergonomic working position
• Small footprint fits conveniently in your space

• Saline removal channel drains decanted saline out of the UltraCW II
• Channel is easily removed for quick cleaning
• Alerts provided for cycle errors and end of program
• Quick-view window aids RPM calibration
• Superior construction including powder-coated body and stainless steel rotor hub minimizes corrosion
• Lid interlock safely prevents lid from opening during operation

• Flexibility of 12-place rotors increases productivity and sample capacity
• Complete antibody identification in one run
• Completed wash cycle in 60 seconds increases productivity and turn-around time
• Set desired decanting speed to achieve optimum results
• Unique rotor design locks tubes in place and spins in the opposite direction during decanting for optimum pellet results
• Eliminates conventional plunger valve and associated bowl cleaning steps

• Diaphragm pump allows saline supply to be located above or below the UltraCW II
• Saline is directly connected to cell washer, eliminating inconvenient saline transfer steps
• Convenient cleaning procedure designed to reduce downtime

• Interface - Color touchscreen input and display
• Power switch - On/Off
• Program capacity - Up to 24 pre-installed and custom programs
• Pre-installed programs - Yes (7)
• Custom programs - Up to 17 additional programs may be created and stored
• Spin cycle- Includes pre-installed spin program. Additional spin programs may be created and stored
• Check step - Check and spin steps can be integrated into programs allowing user to run wash cycles, add reagents, and then spin
• Clean program (Flush) - Yes
• Security - Safety lid interlock prevents lid from opening during operation
• Alerts - Audible-errors (2 sec intervals), audible - end of program (10 sec intervals), visual - end of process

• Power plug - 115V 60HZ NEMA-5, 230V 50/60Hz CEE 7, 230V 50/60Hz SASO
• Certification / Agency listing - QPS (Certified to UL and CSA standards)
• EMC - IEC61326-3-2 / FCC CFR47 part 15, ed 2015, class B
• Indoor/Outdoor Use - Indoor use only
• Application environment - Non-corrosive, non-flammable, non-explosive, 18?C to 30?C (64.4?F to 86?F)
